As a well-known Chinese brand in the field of heavy-duty hard cutting, Valin CBN tools solve the problem of low processing efficiency of large high hardness wear-resistant castings (high chromium cast iron pumps, high manganese steel wear-resistant parts, etc.), and better achieve the balance of wear resistance and impact resistance compared with other CBN tools in the industry. In China, South Africa, Peru, Chile, India, Brazil, Australia, Thailand, Russia, Vietnam, Pakistan and other countries used in the processing of mining wear-resistant castings and received high praise.
Halnn CBN Insert Grade for Wear Parts
Insert Grade | Suited Materials | Machining Type | Typical Application |
BN-K1 | Chilled Cast Iron, Hi-Ni-Cr Cast Iron and High harness alloy cast iron | Roughing | Alloy Cast Iron, Slurry Pump, Wear resistant castings |
BN-S20 | Hardened Steel, Heat and abrasive resistant steel, High manganese steel | Roughing, Semi-Finishing | HSS Rolls, Ball Screw, Wind Power Bearings |
Halnn Recommend Cutting Condition of BN-K1 and BN-S20
| Machining Materials | Process | Cutting Speed Vc(m/min) | Cutting Depth ap | Feed Rate Fr | Recommend CBN Grade |
High Hardness Cast Iron (HRC35-68） | Roughing | 35-120 | 1-10 | 0.15-1.0 | BN-K1 |
Hardened Steel（≥HRC45） | Roughing | 50-150 | 1-10 | 0.1-0.5 | BN-S20 |
CBN Insert Solutions for High Manganese Steel Parts Application Case
BN-S20 Turning High Manganese Steel Crushing Cone | |||
| Materials: High Manganese Steel | ||
Insert Materials | Cutting Speed | Depth of Cut | Tool Life/edge |
Halnn BN-S20 | 65m/min | 7.5mm | 2 pcs |
Carbide Insert | 19m/min | 3.5mm | 0.5 pcs |
BN-S20 Milling High Manganese Steel Liner | |||
| Materials: High Manganese Steel Plate | ||
Insert Materials | Cutting Speed | Feed Rate | Tool Life/edge |
Halnn BN-S20 | 75m/min | 0.2mm/r | 270min |
Carbide Insert | 25m/min | 0.15mm/r | 25min |
CBN Insert Solutions for Pump
Component: Slurry Pump (Impurities pumps, mud pumps, water pumps), impeller, liner, Cylinder liner,ect(Materials: Cr15Mo3, Cr15Mo2Cu,KmTBCr12,Cr20,Cr26 High Chromium alloy cast iron, white cast iron)，Selected CBN Grade: BN-K1 Solid CBN Insert，Common Models: SNMN1207,CNMN1204,RNMN1204
| BN-K1 Turning Slurry Pump Body | ||
| Component:Slurry Pump Body | |
Insert Materials | Lifetime/blade | Failure Mode |
Halnn BN-K1 | 85 pieces | Normal Wear |
Some Brand CBN | 35 pieces | Damage Rupture |
| BN-K1 CBN Inserts Turning Slurry Pump Body | ||
| Component:Slurry Pump Body | |
Insert Materials | Lifetime/blade | Efficiency |
Halnn BN-K1 | 85 pieces | Improved 3 Times |
Some Brand CBN | 35 pieces | ---- |
BN-K1 Turning Slurry Pump Impeller | ||
| Component:Slurry Pump impeller | |
Insert Materials | Lifetime/blade | Failure Mode |
Halnn BN-K1 | 11 pieces | Normal Wear |
Some Brand CBN | 3 pieces | Damage Rupture |
CBN Insert Solutions for Wear Steel Parts Application Case
| BN-K1 CBN Inserts Turning Impeller | ||
| Component:Slurry Pump Impeller | |
Insert Materials | Lifetime/blade | Failure Mode |
Halnn BN-K1 | 2PCS/Blade | Normal Wear |
Some Brand CBN | ＜1PCS/Blade | Damage Rupture |
BN-K1 Machining High Chromium Cast Iron Wear Steel | ||
| Materials: High chromium alloy cast iron,HRC60, Heavy interrupt cutting | |
Insert Materials | Width of Cut | Failure Mode |
Halnn BN-K1 | 500mm | Normal Wear |
Some Brand CBN | 150mm | Damage Rupture |
